USB Configuration
Figure 35. USB Configuration
Table 28. USB Configuration
Parameter Settings Description
USB Mass Storage Driver
Support
Disabled, Enabled Enable/disable USB mass storage driver support.
USB hardware delays and time-outs:
USB transfer time-out 1 sec, 5 sec, 10 sec, 20 sec The time-out value for Control, Bulk, and Interrupt transfers.
Device reset time-out 10 sec, 20 sec, 30 sec, 40 sec USB mass storage device start unit command time-out.
Device power-up delay Auto, Manual Maximum time that the device takes to properly report itself
to the host controller. Auto uses the default value. For a root
port, it is 100 ms; and for a hub port, the delay is taken from
the hub descriptor.
BIOS Setup 41
