Power Management
Figure 31. Power Management
Table 24. Power Management
Parameter Settings Description
State After G3 Power On, Power Off, Last
State
Specify what state to go to when power is re-applied after a
power failure (G3 state).
RTC Wake system from S5 Disabled, FixedTime,
DynamicTime
Enable or disable system wake on alarm event. Select
FixedTime, system will wake on the hr::min::sec specified.
Select DynamicTime, system will wake on the current time +
increase minute(s).
Wake up hour 0 Range: 0–23 hr
Wake up minute 0 Range: 0–59 min
Wake up second 0 Range: 0–59 sec
Wake up minute increase 1 Range: 1–5 min
Ring Wake Disabled, Enabled Disable/enable RI ping for Wake On Ring function (PCH
PME# signal).
PCIe Wake Enabled, Disabled Disable/enable PCI Express wake capability.
36 BIOS Setup
