Table 51. RF antenna interface LTE/5G NR (continued)
Conditions Tx PRx DRx PRX MIMO DRX MIMO Unit
LTE 800 Band 26 23.8 –99.5 –101
a a
dBm
LTE 800 Band 28 23.0 –99.5 –99.5
a a
dBm
LTE 700 Band 29 - –99.5 –101
a a
dBm
LTE 2300 Band 30 22.2 –96.5 –97 –97.5 –96.5 dBm
LTE 1500 Band 32 - –98 –98
a a
dBm
LTE 2000 Band 34 23.3 –97.5 –97.5
a a
dBm
LTE 2600 Band 38 23.8 –98 –97 –96.5 –97 dBm
LTE 1900 Band 39 23.8 –97 –98
a a
dBm
LTE 2500 Band 41 23.4 –97 –97 –97.5 –96.5 dBm
LTE 3500 Band 42 23.5 –98 –98 –97 –97.5 dBm
LTE 5200 Band 46 - –97.5 –97
a a
dBm
LTE 3500 Band 48 21.3 –98 –98 –97.5 –97 dBm
LTE AWS-3 Band 66 23.4 –97 –98 –98.5 –98 dBm
LTE 600 Band 71 23.3 –99.5 –102
a a
dBm
5G NR 2100 Band n1 23.7 –92 –93 –93 –93 dBm
5G NR 1900 Band n2 23.5 –92 –92.5 –92 –92 dBm
5G NR 1800 Band n3 23.3 –92 –92 –92.5 –93 dBm
5G NR 850 Band n5 22.8 –93 –93
a a
dBm
5G NR 2600 Band n7 23.4 –92.5 –93 –92 –93 dBm
a.
No 4x4 MIMO.
Wireless Specifications 73
