Dell Latitude XT3 User Manual

Installing the Display Panel
1. Place the display panel onto the keyboard.
2. Connect the LVDS and the touchscreen cables to the display panel.
3. Rotate the display panel over the top cover.
4. Tighten the screws to secure the display panel.
5. Replace the display bezel.
6. Replace the battery.
7. Follow the procedures in After Working Inside Your Computer.
105

Dell Latitude XT3 Specifications

General

Memory	Up to 8GB DDR3
Graphics	Intel HD Graphics 3000
Operating System	Windows 7 Professional
Wireless	Wi-Fi 802.11 a/b/g/n, Bluetooth 3.0
Processor	Intel Core i5 or i7
Display	13.3-inch HD (1366 x 768)
Storage	Up to 320GB HDD
Battery	6-cell
Touchscreen	Yes
Ports	USB 2.0, HDMI, VGA, RJ-45
Webcam	Yes
