Dell Latitude XT3 - Heat Sink; Removing the Heat Sink

13
Heat Sink
Removing the Heat Sink
1. Follow the procedures in Before Working On Your Computer.
2. Remove the battery.
3. Remove the back panel.
4. Remove the hard drive assembly.
5. Remove the base cover.
6. Disconnect the fan cable from the system board
55
