Dell Latitude XT3 User Manual

29
Display Bezel
Removing the Display Bezel
1. Follow the procedures in Before Working On Your Computer.
2. Remove the battery.
3. Disengage the display bezel from the right edge and remove the top and the bottom
bezel.
Installing the Display Bezel
1. Place the display bezel in line with the top cover.
2. Start from the lower corner and press the display bezel until it snaps into place.
3. Replace the battery.
4. Follow the procedures in After Working Inside Your Computer.
91

Dell Latitude XT3 Specifications

General

Memory	Up to 8GB DDR3
Graphics	Intel HD Graphics 3000
Operating System	Windows 7 Professional
Wireless	Wi-Fi 802.11 a/b/g/n, Bluetooth 3.0
Processor	Intel Core i5 or i7
Display	13.3-inch HD (1366 x 768)
Storage	Up to 320GB HDD
Battery	6-cell
Touchscreen	Yes
Ports	USB 2.0, HDMI, VGA, RJ-45
Webcam	Yes
