Dell Latitude XT3 - Speaker; Removing the Speakers

22
Speaker
Removing the Speakers
1. Follow the procedures in Before Working On Your Computer.
2. Remove the battery.
3. Remove the back panel.
4. Remove the keyboard trim.
5. Remove the hard drive assembly.
6. Remove the base cover.
7. Remove the ExpressCard reader.
8. Remove the palmrest.
9. Disconnect the smart card reader and bluetooth cables from the system board.
81
