Dell Latitude XT3 - Wireless Switch; Removing the WLAN Switch Board

21
Wireless Switch
Removing the WLAN Switch Board
1. Follow the procedures in Before Working On Your Computer.
2. Remove the battery .
3. Remove the back panel.
4. Remove the keyboard trim.
5. Remove the hard drive assembly.
6. Remove the base cover.
7. Remove the palmrest.
8. Disconnect the WLAN switch board flex cable from the system board.
79
