Mini Tower Computer Parts 173
7
Connect the data cable to the system board.
8
Check all cables to be certain that they are properly connected and firmly
seated.
9
Replace the computer cover (see "Replacing the Computer Cover" on
page 207).
NOTICE: To connect a network cable, first plug the cable into the network port or
device and then plug it into the computer.
10
Connect your computer and devices to electrical outlets, and then turn
them on.
1 hard-drive data cable 2 hard-drive data connector on system
board
3 power cable
3
2
1
