NOTE: SATA is configured to support
RAID mode.
USB Controller Allows you to control the USB controller.
The options are:
• Enable Boot Support
• Enable External USB Port
Default Setting: Enable USB Controller and
Enable External USB Port
Miscellaneous Devices Allows you to enable or disable the
following devices:
• Internal Modem
• Microphone
• eSATA Ports
• Hard Drive Free Fall Protection
• Module Bay
• ExpressCard
• Camera
You can also enable or disable:
• Media Card and 1394
• Enable Media Card only
• Disable Media Card and 1394
Default Setting: Media Card and 1394.
Keyboard illumination Allows you to configure the keyboard
illumination feature. The options are:
• Disabled
• Level is 25%
• Level is 50%
• Level is 75%
• Levels is 100%
Default Setting: Level is 25%
Drives Allows you to configure the SATA drives
on board. The options are:
• SATA-0
120
