Dell Precision M6600 - WLAN Card Installation and Removal; Removing the WLAN Card

Wireless Local Area Network
(WLAN) Card 13
Removing Wireless Local Area Network (WLAN) Card
1. Follow the procedures in
Before Working On Your Computer .
2. Remove the battery .
3. Remove the base cover .
4. Disconnect any antennas that may be connected to the WLAN card.
5. Remove the screw that secures the WLAN card to the computer.
6. Remove the WLAN card.
39
