Delphi Multec 3.5 User Manual

Appendix Multec 3.5 Fuel Injector Application Manual
10-10
Delphi Energy and Chassis Systems
Revision: 11/05-1
CHARACTERISTIC APPLICATION
MANUAL
SECTION(S)
CAPABILITY/
RECOMMENDATION
VERIFICATION
RESULT
5.2.3.14
5.3.6
Utilize fuel pump correction
Minimum Pulse
Width
3.9.1
5.2.1.4.1
5.2.2.5
Meet application
recommendation
Interface:
Stack-up
3.2.2
3.3.1
3.8
4.2.1
Ensure no solid contact of
injector with any other surface
3.2.2
3.3.1
4.2.1
Ensure clearance
recommendations are met
3.2.2
4.2.1
Ensure injector cup and
manifold interfaces are correct
3.2.2
3.3.5
4.2.1.1
Ensure injector stays in rail if
clip missing
3.8
5.2.3.12
8.4.8
Minimize wall wetting from
spray
3.3.1
4.2.1
Injector meets application
packaging requirements
3.3.5
3.5.1
4.2.2
Injector oriented properly
Contamination
7.3.4
3.12
10 micron in-line filter utilized
Wiring
3.6.2 Use “high-side” drive circuit
for alcohol fuel applications
4.4.2 Dedicated wiring for injectors
4.4.2 Proper routing
4.4.4 Use proper connector
4.4.3 Maintain polarity
4.4.4 Use non-wicking wire
Controller
