Delphi Multec 3.5 User Manual

Multec 3.5 Fuel Injector Application Manual Appendix
Delphi Energy and Chassis Systems
Revision: 11/05-1 10-11
CHARACTERISTIC APPLICATION
MANUAL
SECTION(S)
CAPABILITY/
RECOMMENDATION
VERIFICATION
RESULT
3.6
3.6.3
4.4.5
Saturated switch driver utilized
Clamping voltage
Avalanche Energy
3.15.2
4.4.5.1
Acceptable to application
Performance:
Appearance
3.2.1 Black and Stainless Steel
acceptable to application
Fuel Pressure
2.2.7.2
3.16
8.4.1
Fuel System pressure robust to
Hot Fuel Handling
Max Flow Rate
3.7
3.16
5.2.3.13
Proper injector sizing
3.9.2 Consider tailbiting when sizing
injector
Flow curve
3.10.1 LFR acceptable to application
3.13 SP acceptable to application
(consider idle condition)
Flow Variation
3.10.2 WFR acceptable to application
5.3.1
5.3.5
Limit parts tested with
diagnostics
7.2.1
8.1.1
9.3.3
Durability flow shift acceptable
to application
Minimum Operating
Voltage
3.6.1 Acceptable to application
Spray
3.8
5.2.5
Cone angle proper for
application
