eZFC-424R4-24 Application Guide

Edition 2.6

Page 31 of 84

Setting Up a Condensate Level Switch

This input is used for a level switch in a condensate pan which alerts the system when a specific

water level in the pan has been exceeded. When the condensate input is active, the algorithm

automatically turns off any active ductal cooling stage to prevent the condensate pan from

overflowing.

1. Next to the input number that you’ve assigned to the condensate pump or control, in the

Function field, select CondensateSwitch.

2. In the Action/Scale field, choose between direct or reverse control.

3. (enteliWEB only) The Input Name field displays the object's name. You can change this

name by clearing the field and entering a new name.

Setting Up Other Supporting Inputs

This topic describes how to set up supporting inputs like fault and window monitoring using the

Local Inputs tab on the configuration page

Set Up an Input

1. Next to the input number that you've assigned to the device, in the Function field, select the

option that applies to your setup:

Function Select this option if you are using a:

AnalogMUX_ Creating an analog input that will be used for monitoring and

will not be used by the algorithm in the controller.

BinaryMUX_ Creating an binary input that will be used for monitoring and

will not be used by the algorithm in the controller.

WindowContact_ Setting up a window contact switch to detect open windows.

When an open window is detected, local heating or cooling

can be disabled as needed to save energy.

FilterStatus_ Adding a filter switch to detect if the fan coil filter is clean or

dirty.

Fault_ Creating an input to monitor the fault status of an equipment.

SpaceTempSetpoint_ Resistive slider or dial to control the space setpoint. The

resistance range must be within 0 to 20 kohms.

2. Select the associated action/scale option for the input.

3. If you had selected the SpaceTempSetpoint_ option to set up a resistive slider, in additional

settings, in the SetpointSliderMinResistance field, enter the minimum resistance of the
