enteliZONE Database Configuration Objects
Page 76 of 84 eZFC-424R4-24 Application Guide
Edition 2.6
Output Configuration Objects
Object Name
Object
Ref
Default Description
TimePropClgMin AV150 0%
The minimum cooling output value. The
time-proportional algorithm scales the
cooling output using this minimum value.
TimePropClgMax AV151 100%
The maximum cooling output value. The
time-proportional algorithm scales the
cooling output using this maximum value.
TimePropHtgMin AV152 0%
The minimum heating output value. The
time-proportional algorithm scales the
heating output using this minimum value.
TimePropHtgMax AV153 100%
The maximum heating output value. The
time-proportional algorithm scales the
heating output using this maximum value.
TimePropPeriod AV154 100s
The period of the pulse that is used to
modulate the time-proportional heating
and cooling outputs.
Heat1FanMin AV199 0
The optional fan speed interlock when
duct Heat 1 stage is running.
Heat2FanMin AV200 0
The optional fan speed interlock when
duct Heat 2 stage is running.
Heat3FanMin AV201 0
The optional fan speed interlock when
duct Heat 3 stage is running.
Cool1FanMin AV202 0
The optional fan speed interlock when
duct Cool 1 stage is running.
Cool2FanMin AV203 0
The optional fan speed interlock when
duct Cool 2 stage is running.
HeatCoolLoad AV802 0 %
Monitors if the system is in heating or
cooling mode (<0 = cooling, >0 =
heating).
Heat1 AV803 100 % First heating stage.
Heat2 AV804 0 % Second heating stage.
Heat3 AV805 0 % Third heating stage.
Cool1 AV806 0 % First cooling stage.
Cool2 AV807 0 % Second cooling stage.
