Delta Controls eZFC-424R4-24 User Manual

LINKnet I/O Tab
Page 40 of 84 eZFC-424R4-24 Application Guide
Edition 2.6
Set Up the Humidity Sensor
1. In the Sensor Options section, next to Space Humidity sensor type, select the Function
option that is most appropriate for your needs:
Function Select this option if:
None The humidity sensor on the eZNS sensor is not used.
MonitoringOnly
The input object AI1003 is created for monitoring only.
Set Up the CO2 Sensor
1. In the Sensor Options section, next to Space CO2 sensor type, select the Function option
that is most appropriate for your needs:
Function Select this option if:
None The CO2 sensor on the eZNS sensor is not used.
DemandControlVentilation Demand controlled ventilation system is used with the
CO2 sensors.
MonitoringOnly
The input object AI1004 created but its value will not be
used by the internal algorithm for space CO2 control.
2. If you selected DemandControlVentilation, in the additional settings, in the
CO2DemandVentSetpoint field, enter the CO2 demand ventilation setpoint value.
3. If you are using CO2 levels to determine occupancy, in the additional settings,
(enteliWEB only) In the CO2 Occupancy On Setpoint field, enter the CO2 setpoint value that
will trigger an occupancy event. To disable CO2-based occupancy detection, set this value to
2000 ppm.
(enteliWEB only) In the CO2 Occupancy Off Setppoint field, enter the CO2 setpoint value
that will cancel an occupancy event.
Set Up the Occupancy Sensor
1. In the Sensor Options section, next to Occupancy Motion sensor type, select the Function
option that is most appropriate for your needs:
Function Select this option if:
None The occupancy sensor on the eZNS sensor is not used.
OccupancyDetection
The motion sensor on the eZNS network sensor is used to
detect occupancy.
