Setting Up Other Outputs
This topic describes how to set up supporting outputs like occupancy indicator on the Local Outputs
tab of the enteliZONE configuration page.
Set Up an Output
1. In the Function field, select the option that applies to your setup:
Function
Select this option if you
are:
OccIndicator_
Setting up an occupancy
output signal.
Any one of the following: ElectricBaseboard_,
HydronicBaseboard_
Controlling radiant heating
equipment.
2PipeChangeOverValve
Controlling a binary water
valve.
GCL-controlled AO_* Creating a custom AO object.
GCL-controlled BO_* Creating a custom BO object.
* Available only with programmable enteliZONE models and only on output terminals that
support AO or BO objects.
For a list of output configuration software objects that correspond to each function, see the
Output Configuration Objects topic.
2. In the Stage field, for the radiant heating equipment, select the radiant heating equipment's
heat stage in the control sequence. If you are using ORCAview,select the heat stage in the
Output Stage field.
Function Stage or Output Stage
OccIndicator_ OccIndicator_ is the default
option.
Any one of the following: ElectricBaseboard_,
HydronicBaseboard_
Select one: Heat1_, Heat2_ or
Heat3_.
2PipeChangeOverValve HeatCoolChangeOverCmd is the
default option.
GCL-controlled AO_ None_ is the default option.
GCL-controlled BO_ None_ is the default option.
