eZFC-424R4-24 Application Guide
Edition 2.6
Page 19 of 84
3. Leave the Password field blank unless a password is defined in the Flash Loader
Password field on the Configuration tab of the controller’s DEV object.
4. Click OK to save changes made in the Settings window.
8. In the device Address field, enter the BACnet device address of the controller you want to
flash. This is the address displayed next to the controller in ORCAview Navigator.
9. In the eZONE section, click the Upgrade to Programmable box to check it.
10. Click Add Features.
Flash Loader transmits the new firmware to the controller. The Status and Progress fields in
the Flash Loader window display the status of the transmission.
11. When the upgrade is complete, the Status field displays an Update Complete message.
12. Close the Flash Loader program.
Fan Coil Programmable Objects
Fan Coil and Heat Pump Programmable Objects
The following table displays all the programmable objects in the fan coil and heat pump enteliZONE
algorithm.
For more information about programmable objects, go to the help topic about programmable
controllers.
Algorithm Unit
Module
Unit Module's Function Programmable Object
Fan Manager Controls the fan sequence.
AV810 Fan1
AV811 Fan2
AV812 Fan3
Controller Manager
Determines the heating and cooling load
on the system.
AV802 HeatCoolLoad
Cooling Stage
Manager
Controls the cooling sequence.
AV806 Cool1
AV807 Cool2
AV810 Fan1
AV811 Fan2
AV812 Fan3
