eZFC-424R4-24 Application Guide
Edition 2.6
Page 13 of 84
To select between multiple controllers:
In the numerical field at the top of the window, enter the BACnet address of the enteliZONE
controller you want to configure and click Connect.
Save to Flash, Save to PC and Load from PC
These buttons are displayed at the top of the configuration graphic dialog. They minimize the need
to switch between the configuration graphic and the ORCAview Navigator when you are working
with multiple controllers.
The Save to Flash button is used to save the controller database to the controller’s flash memory.
The Save to PC button is used to save the controller database .pdb file to your computer.
The Load from PC button is used to load a controller database .pdb file from your computer onto
the enteliZONE controller.
Both Save to PC and Load from PC allow you to save your configuration graphic settings and copy
them onto multiple enteliZONE controllers using ORCAview.
Shortcuts
There is a quick way to open the ORCAview object dialogs by right-clicking on the configured input
and output numbers in the configuration graphic.
In the example below, when you right-click on the number 1 and select Open SpaceTemp_AI1,
the AI1 object dialog opens onscreen.
