Delta Controls eZFC-424R4-24 User Manual

eZFC-424R4-24 Application Guide
Edition 2.6
Page 77 of 84
Object Name
Object
Ref
Default Description
Fan1 AV810 0 % First fan stage.
Fan2 AV811 0 % Second fan stage.
Fan3 AV812 0 % Third fan stage.
DemandCtrlVent AV813 0 %
Demand Control Ventilation. Directly
controls ventilation damper position (fan
coil).
Custom1* AV815 0 %
Custom stage associated with GCL
controlled output.
Custom2* AV816 0 %
Custom stage associated with GCL
controlled output.
HeatCool ChangeOver-
Cmd
MV805 NotUsed_
Used to display the status of the reversing
valve in a heat pump.
ManualFanOccInterlock BV104 Off
Select On if you want a manual fan
command to act as an occupancy signal.
Otherwise select Off if occupancy is
determined by schedule.
* Available only with enteliZONE programmable models.
Setpoint Configuration Objects
Object Name
Object
Ref
Default Description
OccHeating Setpoint AV100 21
Celsius
Base heating setpoint in occupied mode
OccCooling Setpoint AV101 24
Celsius
Base cooling setpoint in occupied mode
UnOccHeating Set-
point
AV102 17
Celsius
Unoccupied heating setpoint
UnOccCooling Set-
point
AV103 21
Celsius
Unoccupied cooling setpoint
