Delta AH Motion Series User Manual

AH Motion – Hardware Manual
4-8
_4
Mount the backplane on a plane by means of M5 screws, as illustrated below. To fix the backplane, you need to
evaluate the length of a screw, the size of a thread, and whether to use a nut according to the actual condition of the
plane unless there are specific specifications for a screw which are indicated in the pictures below.
1. Tighten the M5 screws in the holes indicated by a.
a
a
2. Tighten the two screws in the holes indicated by b.
ｂ
ｂ
 Installing a DIN rail
1. The installation is applicable to a 35 millimeter DIN rail.
2. Install the mounting clips on a backplane.
