Chapter 4 Installation and Wiring
4-53
4_
Wiring differential output terminals on AH05PM-5A / AH10PM-5A / AH15PM-5A, and an ASDA-B series AC servo
drive
FP
RP
Y0.2+
Y0.2-
Y0.3+
Y0.3-
/PLS
21
PLS
22
/SIGN
19
SIGN
20
AC servo drive
Optocoupler circuit
Optocoupler circuit
Wiring differential output terminals on AH05PM-5A / AH10PM-5A / AH15PM-5A, and an ASDA-AB series AC servo
drive
FP
RP
Y0.4+
Y0.4-
Y0.5+
Y0.5-
PLS
43
/PLS
41
SIGN
36
/SIGN
37
AC servo drive
Photocoupler circuit
Photocoupler circuit
