Delta AH Motion Series User Manual

AH Motion – Hardware Manual
4-62
_4
3. External terminal module for AHxxEMC-5A: UB-10-IO22C or DVPAETB-IO22C
COM
COM
COM
COM
S/S
X1.5
S/S
X1.4
S/S
X0.3
S/S
X0.2
X0.1-
X0.11-
X0.10-
X0.0-
X0.9-
X0.8-
24G
24G
FE
Y0.11 Y0.10 Y0.9 Y0.8 X1.3 X1.2 X1.1 X1.0 X0.15 X0.14 X0.13 X0.12 X0.1+
X
0.11+
X
0.10
+
X0.0+ X0.9+ X0.8+ N/C 24V 24V
4. External terminal module for AH10PM-5A: UB-10-IO24C or DVPAETB-IO24C
1
st
from the
upper left
C3 C2 C1 C0 N/C Y0.7- Y0.6- Y0.5- Y0.4- Y0.3- Y0.2- Y0.1- Y0.0- N/C
15
th
from the
upper left
N/C X0.15 X0.13 X0.11 X0.9 N/C N/C X0.3- X0.2- X0.1- X0.0- 24G 24G FE
1
st
from the
lower left
Y0.11 Y0.10 Y0.9 Y0.8 N/C Y0.7+ Y0.6+ Y0.5+ Y0.4+ Y0.3+ Y0.2+ Y0.1+ Y0.0+ N/C
15
th
from the
lower left
S/S X0.14 X0.12 X0.10 X0.8 N/C N/C X0.3+ X0.2+ X0.1+ X0.0+ N/C 24V 24V
