Delta AHCPU560-EN2 Series User Manual

Chapter 8 CIP Object
8-9
8_
 Class
 Class ID: 16#02
 Instance
 16#00: Class Attribute
 16#01: Instance Attribute
 When Instance = 0, the Class Attributes are listed below.
Class
Attribute
Name
Access
Rule
Data Type Values Description
16#01 Revision Get UINT 16#01 Revision of this object
 When Instance = 0, the Instance Attributes are listed below.
Instance
Attribute
Name
Access
Rule
Data Type Values Description
16#02 Number Available Get UINT 16#0
The maximum number of
connections
16#03 Number Active Get UINT 16#0
The number of connected
connections
8.5 Assembly Object (Class ID: 16#04)
8.5.1 AHCPU5x1-EN and AH10EN-5A
It binds attributes of multiple objects, which allows data to or from each object to be sent or received over a single
connection and can be used to bind input data or output data.
 Service Code
Service
Code
Service Name
Support
Description
Class Attribute Instance Attribute
16#0E Get_Attribute_Single V V Read a single attribute
16#10 Set_Attribute_Single X V Edit a single attribute
 Class
 Class ID：16#04
 Instance
 16#00：Class Attribute
 16#64：I/O Connection Output 1
 16#65：I/O Connection Input 1
 16#66：I/O Connection Output 2
 16#67：I/O Connection Input 2
 16#72：I/O Connection Output 8
 16#73：I/O Connection Input 8
 16#74~16#7A Reserved
 16#80：Configuration 1
 16#81：Configuration 2
 16#87：Configuration 8
