Delta AHCPU560-EN2 Series User Manual

EtherNet/IP Operation Manual
8-34
_8
Instance
Attribute
Name
Access
Rule
Data
Type
Values
Description
16#06
Scan Time (0.1ms)
Get
UINT
--
16#07
RTU Status Get UINT
16#0
bit0~1
00: normal
01: alarm
10: error
11: error; the system keeps
running
16#08
Backplane Status Get UINT
16#0
bit0~7 = backplane 1~8
0: setting parameters in the
software cannot be matched
with the device configurations
1: setting parameters in the
software can be matched
with the device configurations
16#09~16#14
Status of the
backplane I/O
modules 0~11
Get UINT
16#0
B0
00: normal;
01: alarm
10: error
B1
B2
0: stop
1: run
B3
0: module not existed
1: existing module
B4
0: the device
configurations cannot be
matched with the setting
parameters
1: the device
configurations can be
matched with the setting
parameters
16#15~16#4C
Status of the I/O
modules 0~7 from
the extension
backplane 1~7
Get UINT
16#0
B0
00: normal;
01: alarm
10: error
B1
B2
0: stop
1: run
16#4D
RTU Error Codes Get UINT
16#0
Refer to AHRTU-ETHN-5A
manual
16#4E~16#59
Error Code of the
backplane I/O
modules
Get UINT
16#0
Error codes of I/O modules
0~11
16#5A~16#91
Error codes of the
I/O modules from
the extension
backplane
Get UINT
16#0
Error codes of the I/O modules
0~7 from the extension
backplane 1~7
8.12.13 Input Register (Class ID: 16#371)
 Service Code
Service Code Service Name
Support
Description
Class Attribute
Instance
Attribute
16#0E Set_Attribute_Single X V
Write one attribute
16#32 Read_Parameter X V
Read Parameter
