Delta AHCPU560-EN2 Series User Manual

Chapter 8 CIP Object
8-33
8_
Instance
Attribute
Name
Access
Rule
Data Type Values Description
1: IP configuration is in process.
2: DHCP configuration is not
complete.
3: IP parameter setting error
16#17~16#2F
Reserved UINT
--
16#30
E-mail 1 Status Register Set UINT
--
0: sending
1: in process
2: E-Mail sent successfully
3~9: Reserved
10: cannot connect to
SMTP-Server
11: Wrong E-Mail recipient address
12: SMTP-Server communication
error
16#31
E-mail 2 Status Register Set UINT
--
16#32
E-mail 3 Status Register Set UINT
--
16#33
E-mail 4 Status Register Set UINT
--
16#34
E-mail 5 Status Register Set UINT
--
16#35
E-mail 6 Status Register Set UINT
--
16#36
E-mail 7 Status Register
Set
UINT
--
16#37
E-mail 8 Status Register Set UINT
--
8.12.12 Status Register (Class ID: 16#370)
 Service Code
Service Code Service Name
Support
Description
Class Attribute
Instance
Attribute
16#0E Get_Attribute_Single X V
Read one attribute
16#33 Write_Parameter X V Write Parameter
 Class
 Class ID：16#370
 Instance
 16#01：Instance Attribute, Word Register
 When Instance = 1, the Class Attributes are listed below.
Instance
Attribute
Name
Access
Rule
Data
Type
Values
Description
16#00
Model Name
Get UINT
16#68C1
System defined;
AHRTU-ETHN-5A module
16#01
System Version
Get UINT
--
System version is shown using
hexadecimal notation; for example,
16#1020 = V1.02.
16#02
Subversion Get UINT
--
System subversion
16#03
Number of
successful TCP
connections
Get UINT
16#0
Number of successful TCP
connections
16#04
Number of
successful CIP
connections
Get UINT
16#0
Number of successful CIP
connections
16#05
Number of
successful
connections via
MODBUS TCP
Server
Get UINT
16#0
Number of successful
connections via MODBUS TCP
Server
