Delta AHCPU560-EN2 Series User Manual

EtherNet/IP Operation Manual
3-4
_3
3.2.2 AH10EN-5A
Item
Specification
General
Category
Scanner /Adapter
Topology
Star, Linear, Ring
CIP Network
I/O Connection
Max. Number of the CIP
Connections
64 (Clients + Servers)
Max. Number of the TCP
Connections
64 (Clients + Servers)
Requested Packet Interval (RPI)
1 ms~1000 ms
Max. Transmission Speed
6400 pps
Max. Data Length
500 bytes
CIP Network
Explicit Message
Class 3 (Connected Type)
Total 32 (Clients + Servers), including the clients +
servers from the UCMM type
UCMM (Non-Connected Type)
Total 32 (Clients + Servers), including the clients +
servers from the Class 3
CIP Objects
Identity Object
（
16#01
）
Message Router Object（16#02）
Assembly Object（16#04）
Connection Manager Object（16#06）
DLR Object（16#47）
QoS Object（16#48）
Port Object（16#F4）
TCP/IP Interface Object（16#F5）
Ethernet Link Object（16#F6）
Vendor specific object：
X Register（16#350）
Y Register（16#351）
D Register（16#352）
M Register（16#353）
S Register（16#354）
T Register（16#355）
C Register（16#356）
HC Register（16#357）
SM Register（16#358）
SR Register（16#359）
Control Register（16#370）
Input Register（16#371）
Output Register（16#372）
3.2.3 AHRTU-ETHN-5A
Item
Specification
General
Category
Adapter
Topology
Star, Linear, Ring
CIP Network
I/O Connection
Max. Number of the CIP
Connections
96
Max. Number of the TCP
Connections
48

Delta AHCPU560-EN2 Series Specifications

General

Brand	Delta
Model	AHCPU560-EN2 Series
Category	Network Hardware
Language	English
