Delta AHCPU560-EN2 Series User Manual

EtherNet/IP Operation Manual
8-36
_8
Instance
Attribute
Name
Access
Rule
Data Type Values Description
Attribute ID 16#0B,
bit 0: I/O module 0 of the main
backplane
bit 1 : I/O module 1 of the main
backplane
bit 11: I/O module 11 of the main
backplane
bit 12: I/O module 0 of the
extension backplane
8.12.14 Output Register (Class ID: 16#372)
 Service Code
Service
Code
Service Name
Support
Description
Class Attribute Instance Attribute
16#0E Set_Attribute_Single X V
Write one attribute
16#32 Read_Parameter X V
Read Parameter
 Class
 Class ID：16#372
 Instance
 16#01：Instance Attribute, Word Register
 When Instance = 16#1, the AH10EN-5A Instance Attributes are listed below.
Instance
Attribute
Name
Access
Rule
Data Type Values Description
16#00~16#09
Reserved
Get
UINT
--
16#0A
Register used for
email triggering
Get UINT
--
1 bit represents one trigger option;
1: sending email
Bit [0~7]: represents email
triggering number 1~8.
16#0B
Data mapping mode Get UINT
--
0: Stop
1: Stop after one execution
2: Continuous execution
16#0C
Register used to store
data mapping 1~16
Get UINT
--
1 bit represents one remote device;
0: not executing
1: executing
Bit [0~15]: represents data
mapping number 1~16.
16#0D
Register used to store
data mapping 17~32
Get UINT
--
16#0E
Register used to store
data mapping 33~48
Get UINT
--
16#0F
Register used to store
data mapping 49~63
Get UINT
--
16#10~16#13
Reserved Get UINT
--
8.12.15 RTU AI Register (Class ID：16#373)
 Service Code
Service
Code
Service Name
Support
Description
Class Attribute Class Attribute
16#0E Get_Attribute_Single X V
Write one attribute
16#32 Read_Parameter X V
Read Parameter
