Delta AHCPU560-EN2 Series User Manual

Chapter 8 CIP Object
8-35
8_
 Class
 Class ID：16#371
 Instance
 16#01：Instance Attribute, Word Register
 When Instance = 16#1, the AH10EN-5A Instance Attributes are listed below.
Instance
Attribute
Name
Access
Rule
Data Type Values Description
16#00
System Status Get UINT
16#0
Display the system status;
0 = Normal
16#01
System Version Get UINT
--
System version is shown using
hexadecimal notation; for example,
16#1020 = V1.02.
16#02
Port X1 Status Get UINT
--
Display the status of Port X1 0:
Link Up
1: Link Down
16#03
Port X2 Status Get UINT
--
Display the status of Port X2
0: Link Up
1: Link Down
16#04~16#05
Reserved Get UINT
--
16#06
MODBUS TCP Client
Connection Status
Get UINT
--
The connection number of the
MODBUS TCP Client.
The connection number of the
MODBUS TCP Server.
16#07
MODBUS TCP Client
Connection Status
Get UINT
--
16#08~16#0A
Reserved Get UINT
--
16#0B
TCP Connection
Status
Get UINT
16#0
The number of the TCP
connections
16#0C
Status of Data
Mapping 1~16
Get UINT
--
One bit represents one remote
device; 0 = success, 1 = failure
16#0D
Status of Data
Mapping 17~32
Get UINT
--
16#0E
Status of Data
Mapping 33~48
Get UINT
--
16#0F
Status of Data
Mapping 49~64
Get UINT
--
16#10
Input Ara Update Time
(ms)
Get UINT
--
The time to complete an update for
input areas.
16#11
Output Area Update
Tme (ms)
Get UINT
--
The time to complete an update for
output areas.
16#12
Normal Exchange
Area Update Time
(ms)
Get UINT
--
The time to complete an update for
both input and output areas.
16#13
System Scan Time
(ms)
Get UINT
--
AH10EN-5A scan time (ms)
The scan time is the cycle of which
the PLC gathers the inputs, runs
your PLC program and then
updates the outputs.
 Instance
 16#1：Instance Attribute, Word Register
 When Instance = 16#1, the AHRTU-ETHN-5A Instance Attributes are listed below.
Instance
Attribute
Name
Access
Rule
Data Type Values Description
16#00
RTU System Status Get UINT
16#0
0 = Normal
1 = Alarm
2: Error
16#01~02
RTU Error Code Get UINT
--
0 = Normal
Others = Error
16#03~16#0A
Reserved
Get
UINT
--
16#0B~16#0F
Module Status Get UINT
--
0 = Normal
1 = Not Normal
