Delta AHCPU560-EN2 Series User Manual

Chapter 8 CIP Object
8-31
8_
 Instance
 16#01：Instance Attribute, Bit Register
 When Instance = 1, the Class Attributes are listed below.
Instance Attribute Name
Access
Rule
Data
Type
Values Description
16#00
SM0 Set BOOL 16#00
SM0 bit register
16#01
SM1 Set BOOL 16#00 SM1 bit register
16#02~16#FFE
SM2~SM4094 Set BOOL 16#00 SM2~SM4094 bit register
16# Max
SMMax Set BOOL 16#00
The maximum number of the
instance attribute is determined
by the sepecifiation of the
connected AH series PLC.
8.12.10 SR Register (Class ID: 16#359)
 Service Code
Service Code Service Name
Support
Description
Class Attribute
Instance
Attribute
16#0E Get_Attribute_Single X V
Read one attribute
16#32 Read_Parameter X V Read Parameter
 Class
 Class ID：16#359
 Instance
 16#01：Instance Attribute, Word Register
 When Instance = 1, the Class Attributes are listed below.
Instance Attribute Name
Access
Rule
Data
Type
Values Description
16#00
SR0
Set
INT
16#00
SR0 word register
16#01
SR1
Set
INT
16#00
SR1 word register
16#02~16#7FE
SR2~SR2046
Set
INT
16#00
SR2~SR2046 word register
16# Max SRMax Set INT 16#00
The maximum number of the
instance attribute is determined
by the sepecifiation of the
connected AH series PLC.
8.12.11 Control Register (Class ID: 16#370)
 Service Code
Service Code Service Name
Support
Description
Class Attribute
Instance
Attribute
16#0E Get_Attribute_Single X V
Read one attribute
