Delta AHCPU560-EN2 Series User Manual

EtherNet/IP Operation Manual
8-32
_8
16#10 Set_Attribute_Single X V
Write one attribute
16#32 Read_Parameter X V Read Parameter
16#33 Write_Parameter X V Write Parameter
 Class
 Class ID：16#370
 Instance
 16#01：Instance Attribute, Word Register
 When Instance = 1, the Class Attributes are listed below.
Instance
Attribute
Name
Access
Rule
Data Type Values Description
16#00
Model Name Get UINT
16#5881
System defined; AH10EN-5A
module
16#01
System Version Get UINT
--
System version is shown using
hexadecimal notation; for example,
16#1020 = V1.02.
16#02
Reserved
UINT
--
16#03
Mode Get UINT
--
0: Single IP, network switch mode
1: Double IP, 2 independent port
mode
16#04
Port X1 IP Address Set UINT
--
Port X1 IP address
16#05
Port X1 IP Address Set UINT
--
16#06
Port X1 Mask Set UINT
--
Port X1 Subnet mask
16#07
Port X1 Mask Set UINT
--
16#08
Port X1 Gateway
Address
Set UINT
--
Port X1 Gateway IP address
16#09
Port X1 Gateway
Address
Set UINT
--
16#0A
Port X1 DHCP Enable Set UINT
16#0
0: Static
1: DHCP
2: BOOTP
16#0B
Port X1 IP Config
Trigger Setup
Set UINT
16#0
0: IP configuration is done.
1: Port X1 IP trigger parameter
setup
16#0C
Port X1 IP Config Status Set UINT
--
0: IP configuration is done.
1: IP configuration is in process.
2: DHCP configuration is not
complete.
3: IP parameter setting error
16#0D
Reserved UINT
--
16#0E
Port X2 IP Address
Set
UINT
--
Port X2 IP Address
16#0F
Port X2 IP Address Set UINT
--
16#10
Port X2 Mask Set UINT
--
Port X2 Subnet mask
16#11
Port X2 Mask Set UINT
--
16#12~13
Reserved UINT
--
16#14
Port X2 DHCP Enable Set UINT
16#0
0: Static
1: DHCP
2: BOOTP
16#15
Port X2 IP Config
Trigger Setup
Set UINT
16#0
0: IP configuration is done.
1: Port X2IP trigger parameter
setup
16#16
Port X2 IP Config Status Set UINT
--
0: IP configuration is done.
