Delta AHCPU560-EN2 Series User Manual

EtherNet/IP Operation Manual
8-14
_8
Instance
Attribute
Name
Access
Rule
Data Type Values Description
16#03
Ring Supervisor
Status
Set USINT 0
Ring Supervisor Active Status Flag,
refer to the following ※2
16#04
Ring Supervisor
Config
Set STRUCT of Ring supervisor parameters
Ring Supervisor
Enable
BOOL 0
Ring supervisor flag
0：Disable
1：Enable
Ring Supervisor
Precedence
USINT 0 Ring supervisor precedence number
Beacon Interval UDINT 400 Ring Beacon interval time (us)
Beacon Timeout UDINT 1960 Ring Beacon timeout (us)
DLR VLAN ID UINT 0
VLAN ID
Range: 0~4094.
16#05 Ring Faults Set UINT 0 Ring fault counter
16#06
Last Active Node on
Port1
Get STRUCT of
Port 1 Ring fault
IP and MAC addresses of the last
active node
Device IP Address UDINT 0 IP address of the device
Device MAC
Address
ARRAY of
6 USINTs
0 MAC address of the device
16#07
Last Active Node on
Port2
Get STRUCT of
Port 2 Ring fault
IP and MAC addresses of the last
active node
Device IP Address UDINT 0 IP address of the device
Device MAC Address
ARRAY of
6 USINTs
0 MAC address of the device
16#08
Ring Protocol
Participants Count
Get UINT 0 Quantity of the devices in the Ring
16#09
Ring Protocol
Participants List
Get
ARRAY of
STRUCT of
IP and MAC addresses of the
devices in the Ring
Device IP Address UDINT 0 IP address of the device
Device MAC Address
ARRAY of
6 USINTs
0 MAC address of the device
16#10
Active Supervisor
Address
Get
STRUCT
of：
--
Ring supervisor IP and MAC
address
Supervisor IP
Address
UDINT 0 Supervisor Device IP address
Supervisor MAC
address
ARRAY of
6 USINTs
0 Supervisor MAC address
16#11
Active Supervisor
Precedence
Get USINT 0 Ring supervisor Precedence value
16#12 Capability Flags Get DWORD 1 refer to the following ※3
