Delta AHCPU560-EN2 Series User Manual

Chapter 5 Programming
5-3
5_
Mode
Setups for the explicit message connection:
0: UCMM: do not create a CIP connection.
1: Connected then close conn; after the transmission is done, close the
connection.
2. Connected then keep conn; after the transmission is done, keep the
connection.
WORD
SerCode (Service Code)
EtherNet/IP standard service code is similar to the function code. The
service codes specify the actions going to take. Delta products support
the following service codes.
0x01 – read every Attribute;
0x0E – read a single one Attribute;
0x05 – reset from the adapter；
0x10 – write a single one Attribute
WORD
ClassId (Class number)
Attribute is the basics of the EtherNet/IP, used for identifying
configurable parameters (Class) within a device.
WORD
InstId (Instance number)
Attribute is the basics of the EtherNet/IP, used for identifying
configurable parameters (Instance) within a device.
WORD
AttrId (Attribute number)
Attribute is the basics of the EtherNet/IP, used for identifying
configurable parameters (Attribute) within a device.
WORD
Size (Parameter type)
If the scanner wants to write a parameter data to the adapter, the
parameter type should be also written in. The unit for this parameter is
byte. When the Size is 1, it means the parameter type is BYTE. When
the Size is 2, it means the parameter type is WORD. When the Size is 4,
it means the parameter type is DWORD.
WORD
Data (Starting value)
If the scanner wants to write a parameter data to the adapter, the
parameter to be written can be typed or can use the starting register
address. The scanner will send the values in the Data to the adapter.
The Data length is determined by the Size. The storing order of the
values in the Data will be little-endian first and then big-endian. If
Data=D0, Size=4, the D0 little-endian will be stored first and then the D0
big-endian, D1 little-endian and then D1 big-endian.
WORD
Don (Completion bit ) When the operation is complete, the Don bit will be On. BOOL
Error (Error bit )
While an error occurs, an Error bit will be On, and an error code will be
shown in the ERRCode.
BOOL
ErrCode (Error code)
Error codes (refer to the following table)
16#00 indicates a successful communication.
WORD
Value (Return Data)
After the function blocks are executed successfully, the AH10EN-5A will
put the read value to the parameter assigned registers, low bytes first
and the high bytes.
WORD
