Delta AHCPU560-EN2 Series User Manual

EtherNet/IP Operation Manual
8-4
_8
Object Name Function Class ID Available for
Port Object
It describes the communication interfaces that are
present on the device and visible to CIP, including
USB, EtherNet/IP and more.
244 (16#F4)
AHCPU5X1-EN
AH10EN-5A
AHRTU-ETHN-5A
TCP/IP Interface
Object
It provides the mechanism to configure a device’s
TCP/IP network interface. Examples of configurable
items include the device’s IP Address, Network
Mask, and Gateway Address.
245 (16#F5) All series
Ethernet Link Object
It maintains link-specific counters and status
information for an IEEE 802.3 communications
interface.
246 (16#F6) All series
X Register Bit/Word Register 848 (16#350) AH10EN-5A
Y Register Bit/Word Register 849 (16#351) AH10EN-5A
D Register Bit/Word Register 850 (16#352) AH10EN-5A
M Register Bit Register 851 (16#353) AH10EN-5A
S Register Bit Register 852 (16#354) AH10EN-5A
T Register Bit/Word Register 853 (16#355) AH10EN-5A
C Register Bit/Word Register 854 (16#356) AH10EN-5A
HC Register Bit/Word Register 855 (16#357) AH10EN-5A
SM Register Bit Register 856 (16#358) AH10EN-5A
SR Register Word Register 857 (16#359) AH10EN-5A
Control Register
AH10EN-5A communication related parameters
880 (16#370)
AH10EN-5A
Stauts Register
AHRTU-ETHN-5A status and the communication
status
AHRTU-ETHN-5A
Input Register Read the status of AH10EN-5A 881 (16#371)
Output Register Trigger AH10EN-5A 882 (16#372)
RTU AI Register
Analog input module value of AHRTU-ETHN-5A 883 (16#373) AHRTU-ETHN-5A
RTU AO Register
Analog output module value of AHRTU-ETHN-5A 884 (16#374) AHRTU-ETHN-5A
RTU DI Register
Digital input module value of AHRTU-ETHN-5A 885 (16#375) AHRTU-ETHN-5A
RTU DO Register
Digital output module value of AHRTU-ETHN-5A 886 (16#376) AHRTU-ETHN-5A
