Delta ASDA-A2 Series User Manual

Appendix A Accessories ASDA-A2
A-4 Revision February, 2017
Delta Part Number: ASD-ABPW0103, ASD-ABPW0105
(for 200V series servo drive, with brake cable)
Title Part No.
L
mm inch
1 ASD- ABPW0103
3000  100 118  4
2 ASD- ABPW0105
5000  100 197  4
Delta Part Number: ASD-CAPW5103, ASD-CAPW5105
(for 400V series servo drive, with brake cable)
Title Part No.
L
mm inch
1 ASD- CAPW5103
3000  100 118  4
2 ASD- CAPW5105
5000  100 197  4

Delta ASDA-A2 Series Specifications

General

Enclosure Rating	IP20
Control Mode	Position, Speed, Torque
Communication Interface	RS-485, CANopen
Protection	Overcurrent, Overvoltage, Undervoltage, Overload, Overtemperature, Encoder error
Operating Temperature	0°C to 55°C
Storage Temperature	-20°C to 65°C
Humidity	20% to 90% RH (non-condensing)
Altitude	1000m max
Cooling Method	Natural cooling or forced air cooling
Encoder Feedback	20-bit incremental encoder (standard), 17-bit absolute encoder (optional)
