ASDA-A2 Chapter 3 Wiring
Revision February, 2017 3-47
C7: Wiring of DO signal. The servo drive applies to the external power and the resistor is
general load.
C8: Wiring of DO signal. The servo drive applies to the external power and the resistor is
inductive load.
