Chapter 7 Optional AccessoriesC2000
7-14
Unit: mm
Model
Input AC reactor
Delta part #
A B C D1*D2 H G G1 Q M PE D
VFD110C23A
DR049AP215 180 195 160 6*12 115 85 122 16 1.2~1.4 M4
VFD150C23A
DR065AP163 180 205 160 6*12 115 85 122 35 2.5~3.0 M4
Table 7-20
