Chapter 12 Description of Parameter SettingsC2000
12.1-00-3
Start-up Display Selection
Default: 0
Settings 0: F (Frequency command)
1: H (Output frequency)
2: U (User defined)
3: A (Output current)
This parameter determines the start-up display page. This is the user defined choice display
according to the setting in Pr.00-04.
Content of Multi-function Display (User-defined)
Default: 3
Settings 0: Display output current (A) (Unit: Amp)
1: Display counter value (c) (Unit: CNT)
2: Display actual output frequency (H.) (Unit: Hz)
3: Display DC BUS voltage (v) (Unit: V
DC
)
4: Display output voltage (E) (Unit: V
AC
)
5: Display output power angle (n) (Unit: deg)
6: Display output power in kW (P) (Unit: kW)
7: Display actual motor speed rpm (r) (Unit: rpm)
8: Display estimate output torque % (t) (Unit: %)
9: Display PG feedback (G) (refer to Pr. 10-00 and Pr. 10-01) (Unit: PLS)
10: Display PID feedback (b) (Unit: %)
11: Display AVI in % (1.) (Unit: %)
12: Display ACI in % (2.) (Unit: %)
13: Display AUI in % (3.) (Unit: %)
14: Display the temperature of IGBT (i.) (Unit: °C)
15: Display the temperature of capacitance (c.) (Unit: °C)
16: The status of digital input (ON/OFF), refer to Pr. 02-12 (i)
17: The status of digital output (ON/OFF), refer to Pr. 02-18 (o)
18: Multi-step speed (S)
19: The corresponding CPU pin status of digital input (d)
20: The corresponding CPU pin status of digital output (0.)
21: Actual motor position (PG1 of PG card) (P.) The maximum value is
32bits display
22: Pulse input frequency (PG2 of PG card) (S.)
23: Pulse input position (PG2 of PG card) (q.) The maximum value is
32bits display
24: Position command tracing error (E.)
25: Overload counting (0.00–100.00%) (o.) (Unit: %)
26: Ground fault GFF (G.) (Unit: %)
27: DC BUS voltage ripple (r.) (Unit: V
DC
)
28: Display PLC register D1043 data (C)
To Next Page
