Delta C2000 Series User Manual

Chapter 12 Description of Parameter SettingsC2000
12.1-00-17
Maximum User-Defined Value
Default: 0
Settings 0: Disable
0–65535 (when Pr. 00-25 set to no decimal place)
0.0–6553.5 (when Pr. 00-25 set to 1 decimal place)
0.00–655.35 (when Pr. 00-25 set to 2 decimal places)
0.000–65.535 (when Pr. 00-25 set to 3 decimal places)
 When Pr. 00-26 is NOT set to 0, the user-defined value is enabled. After selecting the displayed
unit and number of decimal points with Pr.00-25, the setting value of Pr.00-26 corresponds to
Pr.01-00 (Maximum motor operating frequency), and then the motor operation frequency has a
linear relationship with the displayed value on the digital keypad.
Example:
When the frequency set in Pr. 01-00 = 60.00Hz, the maximum user-defined value for Pr. 00-26
is 100.0%. This also means Pr. 00-25 is set at 0021h to select % as the unit.
NOTE
The drive display is controlled by the Pr. 00-25 setting when Pr. 00-25 is properly set and
Pr.00-26 is not 0.
User-Defined Value
Default: Read only
Settings Read only
 Pr. 00-27 displays the user-defined value when Pr. 00-26 is not set to 0.
 The user-defined function is valid only when Pr. 00-20 (frequency source) is set to digital keypad
or RS-485 communication.
LOCAL / REMOTE Mode
Default: 0
Settings 0: Standard HOA function
1: When switching between local and remote, the drive stops
2: When switching between local and remote, the drive runs with REMOTE
settings for frequency and operation status
3: When switching between local and remote, the drive runs with LOCAL
settings for frequency and operation status
4: When switching between local and remote, the drive runs with LOCAL
setting when switched to Local and runs with REMOTE settings when
switched to Remote for frequency and operation status.
 The default of Pr. 00-29 is 0 (standard Hand-Off-Auto function). Set the AUTO frequency and
operation source with Pr.00-20 and Pr.00-21. Set the HAND frequency and operation source with
Pr.00-30 and Pr.00-31. Select or switch AUTO / HAND mode by using the digital keypad
(KPC-CC01) or setting the multi-function input terminal MI = 41, 42.
 When you set the external terminal (MI) to 41 and 42 (AUTO / HAND mode), Pr.00-29 = 1,2,3,4
are disabled. The external terminal has the highest command priority, and Pr. 00-29 functions in
standard HOA mode.
 When you do not set Pr.00-29 to 0, the Local / Remote function is enabled, and the top right
corner of digital keypad KPC-CC01 (optional) displays LOC or REM (the display is available

Delta C2000 Series Specifications

General

Operating Temperature	-10°C to 50°C
Storage Temperature	-20°C to 60°C
Overload Capacity	150% of rated current for 60 seconds
Communication	DeviceNet
Protection	Overvoltage, Undervoltage, Overcurrent, Overload, Overheat
Humidity	5% to 95% (non-condensing)
Cooling	Forced air cooling
Control Mode	V/F Control, Sensorless Vector Control
