Delta C2000 Series User Manual

Chapter 12 Description of Parameter SettingsC2000
12.1-06-12
Fault Code
bit0 bit1 bit2 bit3 bit4 bit5 bit6
current Volt. OL SYS FBK EXI CE
0: No fault record
1: Over-current during acceleration (ocA)
●
2: Over-current during deceleration (ocd)
●
3: Over-current during constant speed(ocn)
●
4: Ground fault (GFF)
●
5: IGBT short-circuit (occ)
●
6: Over-current at stop (ocS)
●
7: Over-voltage during acceleration (ovA)
●
8: Over-voltage during deceleration (ovd)
●
9: Over-voltage during constant speed (ovn)
●
10: Over-voltage at stop (ovS)
●
11: Low-voltage during acceleration (LvA)
●
12: Low-voltage during deceleration (Lvd)
●
13: Low-voltage during constant speed (Lvn)
●
14: Low-voltage at stop (LvS )
●
15: Phase loss protection (OrP)
●
16: IGBT over-heat (oH1)
●
17: Capacitance over-heat (oH2)
●
18: tH1o (TH1 open)
●
19: tH2o (TH2 open)
●
21: Drive over-load (oL)
●
22: Electronics thermal relay protection 1 (EoL1)
●
23: Electronics thermal relay 2 protection (EoL2)
●
24: Motor PTC overheat (oH3) (PTC / PT100)
●
26: Over-torque 1 (ot1)
●
27: Over-torque 2 (ot2)
●
28: Low current (uC)
●
29: Home limit error (LMIT)
●
30: Memory write-in error (cF1)
●
31: Memory read-out error (cF2)
●
33: U-phase current detection error (cd1)
●
34: V-phase current detection error (cd2)
●
35: W-phase current detection error (cd3)
●
36: Clamp current detection error (Hd0)
●
37: Over-current detection error (Hd1)
●
38: Over-voltage detection error (Hd2)
●
39: IGBT short-circuit detection error (Hd3)
●
40: Auto-tuning error (AUE)
●

Delta C2000 Series Specifications

General

Operating Temperature	-10°C to 50°C
Storage Temperature	-20°C to 60°C
Overload Capacity	150% of rated current for 60 seconds
Communication	DeviceNet
Protection	Overvoltage, Undervoltage, Overcurrent, Overload, Overheat
Humidity	5% to 95% (non-condensing)
Cooling	Forced air cooling
Control Mode	V/F Control, Sensorless Vector Control
