Delta C2000 Series User Manual

Chapter 12 Description of Parameter SettingsC2000
12.1-06-13
Fault Code
bit0 bit1 bit2 bit3 bit4 bit5 bit6
current Volt. OL SYS FBK EXI CE
41: PID feedback loss (AFE)
●
42: PG feedback error (PGF1)
●
43: PG feedback loss (PGF2)
●
44: PG feedback stall (PGF3)
●
45: PG slip error (PGF4)
●
48: Analog current input loss (ACE)
●
49: External fault input (EF)
●
50: Emergency stop (EF1)
●
51: External Base Block (bb)
●
52: Password error (Pcod)
●
54: Communication error (CE1)
●
55: Communication error (CE2)
●
56: Communication error (CE3)
●
57: Communication error (CE4)
●
58: Communication time-out (CE10)
●
60: Brake transistor error (bF)
●
61: Y-connection/∆-connection switch error (ydc)
●
62: Deceleration Energy Backup error (dEb)
●
63: Slip error (oSL)
●
64: Electromagnet switch error (ryF)
●
65: PG Card Error (PGF5)
●
68: Sensorless estimated speed have wrong
direction
●
69: Sensorless estimated speed is over speed
●
70: Sensorless estimated speed deviated
●
72: Channel 1 (STO1–SCM1) safety loop error
(STL1)
●
73: External safety gate S1
●
75: external brake error
●
76: Safe Torque Off (STO)
●
77: Channel 2 (STO2–SCM2) safety loop error
(STL2)
●
78: Internal loop error (STL3)
●
82: U phase output phase loss (OPHL)
●
83: V phase output phase loss (OPHL)
●
84: W phase output phase loss (OPHL)
●
85: PG-02U ABZ hardware disconnection
●
86: PG-02U UVW hardware disconnection
●

Delta C2000 Series Specifications

General

Operating Temperature	-10°C to 50°C
Storage Temperature	-20°C to 60°C
Overload Capacity	150% of rated current for 60 seconds
Communication	DeviceNet
Protection	Overvoltage, Undervoltage, Overcurrent, Overload, Overheat
Humidity	5% to 95% (non-condensing)
Cooling	Forced air cooling
Control Mode	V/F Control, Sensorless Vector Control
