Delta C2000 Series User Manual

Chapter 12 Description of Parameter SettingsC2000
12.1-06-15
Output Frequency at Malfunction
Default: Read only
Settings 0.00–599.00 Hz
 When a malfunction occurs, check the current output frequency. If it happens again, it overwrites
the previous record.
Output Voltage at Malfunction
Default: Read only
Settings 0.0–6553.5 V
 When a malfunction occurs, check the current output voltage. If it happens again, it overwrites the
previous record.
DC Voltage at Malfunction
Default: Read only
Settings 0.0–6553.5 V
 When a malfunction occurs, check the current DC voltage. If it happens again, it overwrites the
previous record.
Output Current at Malfunction
Default: Read only
Settings 0.0–6553.5 Amp
 When a malfunction occurs, check the current output current. If it happens again, it overwrites the
previous record.
IGBT Temperature at Malfunction
Default: Read only
Settings -3276.7–3276.7ºC
 When a malfunction occurs, check the current IGBT temperature. If it happens again, it
overwrites the previous record.
Capacitance Temperature at Malfunction
Default: Read only
Settings -3276.7–3276.7ºC
 When a malfunction occurs, check the current capacitance temperature. If it happens again, it
overwrites the previous record.
Motor Speed in rpm at Malfunction
Default: Read only
Settings -32767–32767 rpm
 When a malfunction occurs, check the current motor speed in rpm. If it happens again, it
overwrites the previous record.

Delta C2000 Series Specifications

General

Operating Temperature	-10°C to 50°C
Storage Temperature	-20°C to 60°C
Overload Capacity	150% of rated current for 60 seconds
Communication	DeviceNet
Protection	Overvoltage, Undervoltage, Overcurrent, Overload, Overheat
Humidity	5% to 95% (non-condensing)
Cooling	Forced air cooling
Control Mode	V/F Control, Sensorless Vector Control
