Chapter 12 Description of Parameter SettingsC2000
12.1-11-4
Unit of induction motor system inertia is kg-cm
2
:
Power Setting Power Setting Power Setting
1HP 2.3 25HP 142.8 175HP 2150.0
2HP 4.3 30HP 176.5 250HP 2800.0
3HP 8.3 40HP 202.5 300HP 3550.0
5HP 14.8 50HP 355.5 375HP 5139.0
7.5HP 26.0 60HP 410.8 425HP 5981.0
10HP 35.8 75HP 494.8 475HP 7053.0
12HP 54.8 100HP 1056.5 600HP 9643.0
15HP 74.3 125HP 1275.3 650HP 10734.0
20HP 95.3 150HP 1900.0 750HP 13000.0
The base value for induction motor system inertia is set by Pr. 05-38 and the unit is in kg-cm
2
.
ASR1 / ASR2 Switch Frequency
Default: 7.00
Settings 5.00–599.00Hz
Sets the low-speed and high-speed ASR switching point in the FOC area. Provides flexibility to
meet two needs: in the high-speed region of the estimator switch point it has a high response,
and in the low-speed region of the estimator switch point it has a lower response. The
recommended switching point is higher than Pr. 10-39.
A low setting does not cover Pr. 10-39. If the setting is too high, the high-speed range is too
narrow.
ASR1 Low-speed Bandwidth
Default: 10
Settings 1–40Hz (IM) / 1–100Hz (PM)
ASR2 High-speed Bandwidth
Default: 10
Settings 1–40Hz (IM) / 1–100Hz (PM)
Zero-speed Bandwidth
Default: 10
Settings 1–40Hz (IM) / 1–100Hz (PM)
After estimating inertia and setting Pr. 11-00 bit0=1 (auto-tuning), you can adjust Pr. 11-03, Pr.
11-04 and Pr. 11-05 separately according to the speed response. The larger the setting value, the
faster the response. Pr. 11-02 is the switch frequency for the low-speed / high-speed bandwidth.
The position control pulse command (MIx=37) and P2P position control Kp gain can adjust Pr.
11-05. The higher the value, the lower the steady-state error.
ASR 1 Gain
Default: 10
Settings 0–40 Hz (IM) / 1–100Hz (PM)
ASR 1 Integral Time
Default: 0.100
Settings 0.000–10.000 sec.
