Delta VFD-V Series User Manual

8
VFD-V Series
DELTA ELECTRONICS, INC. ALL RIGHTS RESERVED
8-23
Control Mode
Parameters Functions Settings
Factory
Setting
VF VG SV SG T TG
5: oL1 (electronic thermal relay)
{ { { { { {
6: EF (external fault)
{ { { { { {
7: CF3 (hardware circuit fault)
{ { { { { {
8: HPF (protection circuit fault)
{ { { { { {
9: ocA (over-current during
accel)
{ { { { { {
10: ocd (over-current during
decel)
{ { { { { {
11: ocn (over-current during
constant speed)
{ { { { { {
12: GFF (ground fault)
{ { { { { {
13: pg error
{ { { { { {
15: CF1 (unable to write to
memory)
{ { { { { {
16: CF2 (unable to read
memory)
{ { { { { {
17: bb (Pause)
{ { { { { {
18: oL2 (motor overload)
{ { { { { {
19: sc (IGBT failure)
{ { { { { {
20: brake (braking transistor
failure)
{ { { { { {
21: OL3 (motor overload)
{ { { { { {
22: oh2 (brake overheat)
{ { { { { {
06-18
2
nd
Most Recent
Fault Record
23: Fuse failure
0
{ { { { { {
24: CT2 (current sensor 2)
{ { { { { {
25: CT1 (current sensor 1)
{ { { { { {
26: PWM (upper and lower
points at the same low level)
{ { { { { {
06-19
3
rd
Most Recent
Fault Record
27: Motor auto tuning failure
0
{ { { { { {
28: PID error
{ { { { { {
29: ACI error
{ { { { { {
31: CC
{ { { { { {
33: VEC R1 out of range (Pr.
05-30)
{ { { { { {
34: keypad error
{ { { { { {
35: RS 485 watchdog timer
{ { { { { {
36: FAN failure
{ { { { { {
06-20
4
th
Most Recent
Fault Record
37: input phase loss
0
{ { { { { {
