Delta VFD-V Series User Manual

8
VFD-V Series
DELTA ELECTRONICS, INC. ALL RIGHTS RESERVED
8-29
Control Mode
Parameters Functions Settings
Factory
Setting
VF VG SV SG T TG
a
10-05 PG Slip Range 0.0~50.0% 10.0
° { ° { ° {
a
10-06
PG Stall Level
(overspeed
protection)
0.0~115.0% 110.0
° { ° { ° {
a
10-07
PG Electrical
Gear A
1~5000 100
° { ° { ° {
a
10-08
PG Electrical
Gear B
1~5000 100
° { ° { ° {
a
10-09
PG Position
Control Point
(Home)
0～20000
0
° { ° { ° {
a
10-10
Range for PG
Position Attained
(Home range)
0～20000
10
° { ° { ° {
a
10-11
PG Encoder input
Filter Time
0.001~1.000 second 0.003
° { ° { ° {
a
10-12
PG04 encoder
input selection
(channel 2)
0: Phase A leads in a forward run
command and phase B leads in
a reverse run command.
(rising/falling edge trigger)
1: Phase B leads in a forward run
command and phase A leads in
a reverse run command.
(rising/falling edge trigger)
2: Phase A is a forward run pulse,
then phase B is High.
Phase B is a reverse run pulse,
then phase A is High.
3: Phase B is a forward run pulse,
then phase A is High.
Phase A is a reverse run pulse,
then phase B is High.
4: Phase A is a pulse input, phase
B is a direction input,
(low = reverse , high =forward)
5: Phase A is a pulse input, phase
B is direction input.
(low = forward, high = reverse)
0
° { ° { ° {
Position Control Parameter
Control Mode
Parameters Functions Settings
Factory
Setting
VF VG SV SG T TG
a
10-13
Proportional (P)
Gain
0.0~500.0% 50.0
° { ° { ° {
0.00~100.00 Sec
a
10-14 Integral (I) Time
0.00: no integral
0.050
° { ° { ° {
