Delta VFD-V Series User Manual

VFD-V Series
DELTA ELECTRONICS, INC. ALL RIGHTS RESERVED
8-30
Control Mode
Parameters Functions Settings
Factory
Setting
VF VG SV SG T TG
a
10-15
Differential (D)
Time
0.00~1.00 Sec
0.25
° { ° { ° {
a
10-16 Orient Speed 0.00~400.00 Hz 5.00
° { ° { ° {
a
10-17 Creep point 0~20000 100
° { ° { ° {
a
10-18 Loop Speed 0.00~400.00 Hz 1.00
° { ° { ° {
a
10-19 Loop Point 0~20000 10
° { ° { ° {
a
10-20
Division (scaling)
factor for
PG04/05
1~128 1
° { ° { ° {
a
10-21 Feed Forward 0.0~100.0%
0
° { ° { ° {
a
10-22
Position Control
Speed Gain
0.0~100.0%
100
° { ° { ° {
a
10-23
PG Position
Attained 2
0〜20000
100
° { ° { ° {
a
10-24
P2P Acceleration
Time
0.00〜100.00 s
1.00
° { ° { ° {
a
10-25
P2P Deceleration
Time
0.00〜100.00 s
1.00
° { ° { ° {
a
10-26
Delay Time for
Position
Command
0.00〜100.00 s
0.005
° { ° { ° {
a
10-27
Position Control
Integral (I) Time 2
0.0〜1500.0%（05-25 switch）
50.0
° { ° { ° {
a
10-28
Position Control
Integral (I) Time 2
0.001〜10.000 s
000: no integral（0.5-25 switch）
0.050
° { ° { ° {
a
10-29
Selection of P2P
Control Mode
0: relative P2P
1: absolute P2P
00000
° { ° { ° {
a
10-30
Direction
Command of
Absolute P2P
0~255 (10-33~40)
0
° { ° { ° {
a
10-31
FWD Limit of
Absolute P2P
1~60000
0: No Limit
0
° { ° { ° {
a
10-32
REV Limit of
Absolute P2P
1~60000
0: No Limit
0
° { ° { ° {
a
10-33 P2P Command 0
0~50000 (in position control 2
mode)
0
° { ° { ° {
a
10-34 P2P Command 1
0~50000 (in position control 2
mode)
0
° { ° { ° {
a
10-35 P2P Command 2
0~50000 (in position control 2
mode)
0
° { ° { ° {
a
10-36 P2P Command 3
0~50000 (in position control 2
mode)
0
° { ° { ° {
