3-9
7.5 HP to 15 HP (VFD055V23A/43A
, VFD075V23A/43A, VFD110V43B)
POWER
IM
MOTOR
3
Control T
erminal
T
orque: 8Kgf-cm (6.9 in-lbf)
Wire: 22-14
A
WG
Power Terminal
T
orque: 30 kgf-cm (26 in-lbf)
Wire Gauge: 12-8
A
WG
Wire T
ype: S
tranded Copper only
, 75
°
C
Note: If wiring of the termina
l utilizes the wire with
a
6A
WG-diameter
, it is thus
necessary to use the Recongnized Ring
T
erminal to conduct a proper wiring.
19
21
