Getting Started Settings Playback Remote ControlMulti-zone Information Troubleshooting Specifications
Connecting Devices
R
L
R
L
R
L
R
L
R
L
R
L
46#
800'&3
$&/5&3 463306/%
#"$,
3-
463306/%
3-
'30/5
3-
"6%*0
Component with Multi-channel Output connectors
The video signal can be connected in the same way as a Blu-ray Disc
player / DVD player (vpage 15 “Blu-ray Disc Player / DVD Player”).
When a device is connected to the SBL/SBR terminal of the external input
terminals (EXT. IN), set “Amp Assign” (vpage 34) to “Normal”.
Blu-ray Disc player / DVD player /
External decoder
To play analog signals input from the external input (EXT. IN)
terminal, set “Input Mode” (vpage 49) to “EXT. IN”.
“EXT. IN” can also be selected with INPUT MODE on the main
unit.
Set as Necessary
USB Port
When you connect an iPod or USB memory device to the USB port, you can enjoy music, etc., stored on the iPod or USB memory device.
Front paneln Rear paneln
Set when you change the USB port for use.
“USB Select” (vpage 51)
Set as Necessary
In the initial status, USB memory devices can be used by connecting
them to the USB port on the front panel.
To connect an iPod to the AVR-4310CI, use the USB cable supplied
with the iPod.
When you want to playback a movie file stored on the iPod, use the
DENON control dock for iPod (ASD-11R or ASD-1R, sold separately)
(vpage 16 “Control Dock for iPod”).
For iPods, playback is possible on iPod touch, classic and nano sold
from generation 5 on. For details, check the Web or page 55.
•
•
•
•
NOTE
You cannot use the USB port on the front panel and rear panel
simultaneously. Select and connect the USB port you are to use.
Do not use an extension cable when connecting a USB memory
device. This may cause radio interference with other devices.
•
•
USB memory
device
iPod
USB memory
device
iPod
or or
Connections
1.AVR4310CIEU.indd 21 2009/04/14 16:36:33
To Next Page
