Denon AVR-4520 Service Manual

Conrmation item Setting and display Details of how to operate remote controller *a)
Output sequence of remote control codes
※
It is useful to form a macro program. *b)
Contents of conrmation Remarks
7
HDMI Audio (signal) Path
(Audio : AVR)
Audio : AVR(When checking the audio output
from AVR)
Display:
V 0 5 D V D
1.Press [AVR]
2.Press [ZONE SELECT], Select "MAIN"
3.Press [5/JKL]
q
KEY 5/JKL (Main Zone)
Initialization & Select Audio AVR
·Input : HDMI (Signal of PCM2ch, DolbyDigital or DTS) / Output :
Speakers
·Input : HDMI (Signal of HD Audio) / Output : Speakers
(
※
As the input source, you can switch from DVD to other ones.)
4.Press [DVD]
w
DVD (Main Zone)
8
HDMI Audio (signal) Path
(Audio : TV)
Audio : TV(When checking the audio output
from TV)
Display:
V 0 6 D V D
1.Press [AVR]
2.Press [ZONE SELECT], Select "MAIN"
3.Press [6/MNO]
q
KEY 6/MNO (Main Zone)
Initialization & Audio Select TV
· Input : HDMI (Signal of PCM2ch ) / Output : HDMI (Audio output from
connected TV)
(
※
As the input source, you can switch from DVD to other ones.)
4.Press [DVD]
w
DVD (Main Zone)
9
HDMI (signal) Path
(ZONE4)
Video Convert(IP Scaler) : OFF, All Sources
MAIN ZONE, ZONE4 : ON
Display:
V 0 1 D V D
1.Press [AVR]
2.Press [ZONE SELECT], Select "MAIN"
3.Press [1/./]
q
KEY1/CODE1 (Main Zone)
Initialization & Video Convert All OFF
·Input : HDMI (ZONE4 Function) / Output : HDMI (ZONE4)
(
※
As the input source, you can switch from DVD to other ones.)
ZONE4 CEC is conrmed you set below.
Setup Menu
→
Video
→
HDMI Setup
→
Control Monitor
→
ZONE4
4.Press [DVD]
w
DVD (Main Zone)
3.4.6. Audiosystemconrmationitems
g.XX : Refer to the block diagram of the g.XXth.
Conrmation item Setting and display Details of how to operate remote controller
Output sequence of remote control codes
※
It is useful to form a macro program.
Contents of conrmation Remarks
1
Analog (signal) Path Input Mode : Fixed ANALOG
SURROUND mode : DIRECT
Amp assign : 9.1ch (SB/FH/FW)
Display:
A 0 1 D V D
1.Press [AVR]
2.Press [ZONE SELECT], Select "MAIN"
3.Press [7/PQRS]
q
KEY 7/PQRS (Main Zone)
Initialization & Amp assign
9.1ch (SB/
FH/FW)
& Input Mode Fixed ANALOG &
SURROUND mode DIRECT
·Input : Analog / Output : Speakers (Front L/R)
·Input : Analog / Output : Pre OUT(Front L/R)
(
※
As the input source, you can switch from DVD to other ones.)
4.Press [DVD]
w
DVD (Main Zone)
2
DIGITAL (signal) Path
(MAIN)
Input Mode : Fixed DIGITAL
Amp assign : 9.1ch (SB/FH/FW)
Display:
A 0 2 D V D
1.Press [AVR]
2.Press [ZONE SELECT], Select "ZONE3"
3.Press [8/TUV]
q
KEY 8/TUV (Main Zone)
Initialization & Amp assign
9.1ch (SB/FH/
FW)
& Input Mode Fixed DIGITAL
·Input : Digital / Output : Speakers (Front L/R)
·Input : Digital / Output : Pre OUT(Front L/R)
(
※
As the input source, you can switch from DVD to other ones.)
4.Press [DVD]
w
DVD (Main Zone)
3
DIGITAL (signal) Path
(ZONE2)
Input Mode : Fixed DIGITAL
Amp assign : 7.1ch+ZONE2
Display:
A 0 3 D V D
1.Press [AVR]
2.Press [ZONE SELECT], Select "ZONE3"
3.Press [9/XYZ]
q
KEY 9/XYZ (Main Zone)
Initialization & Amp assign
7.1ch+ZONE2
& Input Mode Fixed DIGITAL
·Input : Network or iPod/USB / Output : Speakers (Front wide L/R)
·Input : Network or iPod/USB / Output : Pre OUT(ZONE2 L/R)
(
※
As the input source, comrm the operation in Network or iPod/USB.)
4.Press [NET/USB]
w
NET/USB (Main Zone)
4
HDMI (signal) Path Input Mode : Fixed HDMI
Amp assign : 9.1ch (SB/FH/FW)
Display:
A 0 5 D V D
1.Press [AVR]
2.Press [ZONE SELECT], Select "MAIN"
3.Press [MOVIE]
q
MOVIE
Initialization &Amp assign
9.1ch (SB/FH/
FW)
& Input Mode Fixed HDMI
·Input : HDMI / Output : Speakers (Front L/R)
·Input : HDMI / Output : Pre OUT(Front L/R)
(
※
As the input source, you can switch from DVD to other ones.)
4.Press [DVD]
w
DVD (Main Zone)
5
A/D (signal) Path
(Main Zone)
Amp assign : 9.1ch (SB/FH/FW)
SURROUND mode : Multi ch STEREO
Vol -20dB
Speaker Cong : SSSSSSY
(Front/Center/Surround/SourroundBack(2sp)/FrontHeight/
FrontWide : Small, SW : Yes(2sp))
Display:
A 0 6 D V D
1.Press [AVR]
2.Press [ZONE SELECT], Select "MAIN"
3.Press [MUSIC]
q
MUSIC
Initialization &Amp assign
9.1ch (SB/
FH/FW)
& SURROUND mode : Multi ch
STEREO & Volume -20dB
·Input : Analog / Output : Speakers (Front L/R)
·Input : Analog / Output : Pre OUT(Front L/R), SW(20Hz)
(
※
As the input source, you can switch from DVD to other ones.)
4.Press [DVD]
w
DVD (Main Zone)
6
Amp Assign (signal) Path
(Amp Assign : ZONE2)
Amp assign : 7.1ch+ZONE2
ZONE2 Function : Source
Zone2 Vol -20dB
Display:
A 0 7 D V D
1.Press [AVR]
2.Press [ZONE SELECT], Select "MAIN"
3.Press [GAME]
q
GAME
Initialization & Amp assign
7.1ch+ZONE2
& SURROUND mode : Multi ch STEREO &
ZONE2 Volume -20dB
·Input : Analog / Output : Speakers (Front wide L/R)
·Input : Analog / Output : Pre OUT (ZONE2 L/R)
(
※
As the input source, you can switch from DVD to other ones.)
4.Press [DVD]
w
DVD (Main Zone)
7
Amp Assign (signal) Path
(Amp Assign : ZONE3)
Amp assign : 5.1ch+ZONE2/3
SURROUND mode : Multi ch STEREO
Zone3 Vol -20dB
Display:
A 0 8 D V D
1.Press [AVR]
2.Press [ZONE SELECT], Select "MAIN"
3.Press [DIRECT]
q
DIRECT
Initialization & Amp assign
5.1ch+ZONE2/3
& SURROUND mode : Multi ch STEREO &
ZONE3 Volume -20dB
·Input : Analog / Output : Speakers (Front wide L/R)
·Input : Analog / Output : Pre OUT (ZONE3 L/R)
(
※
As the input source, you can switch from DVD to other ones.)
4.Press [DVD]
w
DVD (Main Zone)
g.7
g.8
g.9
g.10
g.11
g.12
g.13
g.14
g.15
g.16
35
