Denon AVR-E400 Service Manual

FRONT
4
REF No. Part No. Part Name Remarks Q'ty New Ver
C4440 nsp X7R)0.047UF-K/25V-1608REEL D011473774161S 1
C4441,4442 nsp COG470PF-J/50V-1608REEL D010471167160S 2
C4443 nsp X7R0.1UF-K/50V-1608REEL D011104577160S 1
C4444 nsp COG100PF-J/50V-1608REEL D010101167160S 1
C4445 nsp COG470PF-J/50V-1608REEL X2000E1C,E2,E3,K D010471167160S 1
C4447 00D9630293602 1UF-M/50V,5*11-5RE.SMS SY (Pb Free) D040010087150S 1
C4448 nsp X7R0.1UF-K/50V-1608REEL D011104577160S 1
C4450 nsp COG470PF-J/50V-1608REEL X2000E1C,E2,E3,K D010471167160S 1
C4453 nsp COG100PF-J/50V-1608REEL D010101167160S 1
C4455,4456 nsp X7R1000PF-K/50V-1608REEL D011102777160S 2
C4459,4460 nsp ST-0.01UF-J/100V-5RE PEFAM103J100 PEF TYPE D02010306C060S 2
C4462 nsp ST-0.1UF-J/100V-5RE PEFAM104J100 PEF TYPE D02010406C060S 1
C4463 nsp ST-0.047UF-J/100V-5RE D02047306C060S 1
C4470 nsp X7R0.1UF-K/50V-1608REEL D011104577160S 1
C4471 nsp 220UF-M/6.3V,8*5-5RE SRE SY D040221081070S 1
C4472 nsp COG 0.001UF-J/50V-1608REEL D010102167160S 1
C4475,4476 nsp X7R0.01UF-K/50V-1608REEL X2000E1C,E2,E3,K D011103777160S 2
C4477,4478 nsp X7R0.01UF-K/50V-1608REEL D011103777160S 2
C4479 nsp X7R0.1UF-K/50V-1608REEL D011104577160S 1
OTHER PARTS GROUP
BD4401-4403 nsp 0-J,1/16W-1608REEL C20000006M160S 3
BD4407 nsp 0-J,1/16W-1608REEL C20000006M160S 1
BD4409,4410 nsp 0-J,1/16W-1608REEL C20000006M160S 2
BD4411 nsp BLM21PG221SN1 220ohm 2A SMD2012 TYPE D340201212210S 1
BKT4400 nsp AVR133(HARMAN) BURRING HOLE SPTE 0.8t/SCREW 4010210196100S 1
CB4400,4401 nsp 0-J,1/16W-1608REEL C20000006M160S 2
CLAMP402,403 nsp HMX9800(ON)(HAITAI) (W=2.6,L=50)/WIRE(SOLDER) 4330000120000S 2
CLAMP405,406 nsp HMX9800(ON)(HAITAI) (W=2.6,L=50)/WIRE(SOLDER) 4330000120000S 2
CN4400 nsp 1.0-11S-40PW 40P AN DIP TOP CONTACT L130100114050S 1
CN4402 nsp 330MM/5P 20010HS-05=CKM2002HV-05 RD2725#24/28 TUBE L002331050150S 1
CP4400 nsp 5268-07A 7P ANGLE L102526800700S 1
CP4401 nsp TUC-P07X-B1 BD-TO-BD 7P HOUSING ST (35237-07) L101100030710S 1
CP4402,4403 nsp TUC-P07P-B1 BD-TO-BD 7P WAFER ST (35336-07) L101100040710S 2
CP4405 nsp TUC-P07X-B1 BD-TO-BD 7P HOUSING ST (35237-07) L101100030710S 1
CP4406 963643101610D USB A F 180 DIP L=15.0 G480040000180S 1
! F4401 963652500020S 6125FF500-R 500mA FAST-ACTING SUBMINIATURE FUSE G657612505030S 1
FL4400 943172100150S 018BT021GINK 129*25*6.1 GREEN /AVR1913 K530180210010S 1
G4400 nsp 160MM/1P 61640-BS=CKM9919T BK1617#22 8410161010120S 1
J4404,4405 nsp JUMPER (0.6/52MM) L045084006040S 2
J4407-4411 nsp JUMPER (0.6/52MM) L045084006040S 5
J4413,4414 nsp JUMPER (0.6/52MM) L045084006040S 2
J4419,4420 nsp JUMPER (0.6/52MM) L045084006040S 2
J4423,4424 nsp JUMPER (0.6/52MM) L045084006040S 2
J4426 nsp JUMPER (0.6/52MM) L045084006040S 1
J4430-4435 nsp JUMPER (0.6/52MM) L045084006040S 6
J4437 nsp JUMPER (0.6/52MM) L045084006040S 1
J4443-4456 nsp JUMPER (0.6/52MM) L045084006040S 14
J4458 nsp 0-J,1/8W-3216REEL C200000061300S 1
J4459 nsp JUMPER (0.6/52MM) L045084006040S 1
J4462-4473 nsp JUMPER (0.6/52MM) L045084006040S 12
J4474 nsp 0-J,1/8W-3216REEL C200000061300S 1
J4475 nsp JUMPER (0.6/52MM) L045084006040S 1
J4477-4479 nsp JUMPER (0.6/52MM) L045084006040S 3
J4481,4482 nsp JUMPER (0.6/52MM) L045084006040S 2
J4484-4491 nsp JUMPER (0.6/52MM) L045084006040S 8
J4493,4494 nsp JUMPER (0.6/52MM) L045084006040S 2
J4498,4499 nsp JUMPER (0.6/52MM) L045084006040S 2
J4501-4505 nsp JUMPER (0.6/52MM) L045084006040S 5
J4507-4545 nsp JUMPER (0.6/52MM) L045084006040S 39
JACK4400 00D9630367802 EARPHONE JACK(PJ-354H-4)(MIC) BLACK G401PJ354H40YS 1
JACK4401 963643101600D PHONE (YUQIU) D6.5 9P NI PJ-621HA G402PJ621HA0YS 1
JP4401,4402 nsp 0-J,1/8W-3216REEL C200000061300S 2
JP4490-4493 nsp JUMPER (0.6/52MM) L045084006040S 4
LED4400 963262010460S SIR-341ST3F 3PI 2.5MM INFLARED LED X2000E3 K505341300010S 1
LED4402 963263100620D BL-BUBGJ201G-L 3PI RED/GREEN K500032501150S 1
RMC4400 963262010290S R34FS9A 38KHZ IR REMOCON MODULE P=2.54MM H=15MM E940349003810S 1
SW4400-4409 00D9630095305 SKHV10910D01 KB581/LG 160G G180040500010S 10
SW4410 00D9630387408 EC16B24SO-ZZZ L=25MM CLICK=24 TORQUE=100-300 G121162400070S 1
SW4411 00D9630095305 SKHV10910D01 KB581/LG 160G G180040500010S 1
SW4412 00D9630387408 EC16B24SO-ZZZ L=25MM CLICK=24 TORQUE=100-300 X2000E1C,E2,E3,K G121162400070S 1

Denon AVR-E400 Specifications

General

HDMI Inputs	6
HDMI Outputs	1
3D Pass-through	Yes
4K Pass-through	Yes
Dolby TrueHD	Yes
DTS-HD Master Audio	Yes
Audyssey MultEQ	Yes
Network Connectivity	Yes
AirPlay	Yes
DLNA	Yes
Input Impedance	47 kOhms
Input Sensitivity	200 mV
Signal-To-Noise Ratio	100 dB
Response Bandwidth	10 Hz - 100 kHz
THD	0.08%
Tuner Presets	56
Tuner Bands	AM/FM
Frequency Response	10 Hz - 100 kHz
Video Upscaling	Yes
Bluetooth	No
Wi-Fi	No
Surround Sound Effects	DTS Neo:6
Audio D/A Converter	192kHz/24-bit
Inputs	HDMI, Digital Optical, Digital Coaxial, Analog
Outputs	HDMI, Headphones
